Nhxmh
TEKNİK ÖZELLİKLER / TECHNICAL FEATURES
| NOMİNAL KESİT | KABLO DIŞ ÇAPI YAKLAŞIK | ORTALAMA AĞIRLIK | 20 º C ‘ de İLETKEN D.A DİRENCİ | AKIM TAŞIMA KAPASİTESİ HAVADA | AKIM TAŞIMA KAPASİTESİ HAVADA |
|---|---|---|---|---|---|
| CROSS-SECTION | OVERALL DIAMETER OF CABLE (APPROX) | WEIGHT (AVERAGE) | CONDUCTOR DC RESISTANCE AT 20 º C | CURRENT CARRYING CAPACITY IN AIR | CURRENT CARRYING CAPACITY IN CONDNIT |
| mm² | mm | g/km | Ω/km | A | A |
| NHXMH |
2 DAMARLI / 2 CORES
| 2×1,5 re | 8,30 | 105 | 12,10 | 18,5 | 22 |
| 2×2,5 re | 9,10 | 134 | 7,41 | 25 | 30 |
| 2×4 re | 10,40 | 188 | 4,61 | 34 | 40 |
| 2×6 re | 11,40 | 242 | 3,08 | 43 | 51 |
| 2×10 rm | 15,10 | 413 | 1,83 | 60 | 70 |
| 2×16 rm | 17,00 | 571 | 1,15 | 80 | 98 |
3 DAMARLI / 3 CORES
| 3×1,5 re | 8,70 | 121 | 12,10 | 18,5 | 22 |
| 3×2,5 re | 9,50 | 158 | 7,41 | 25 | 30 |
| 3×4 re | 10,80 | 237 | 4,61 | 34 | 40 |
| 3×6 re | 12,30 | 309 | 3,08 | 43 | 51 |
| 3×10 rm | 15,60 | 506 | 1,83 | 60 | 70 |
| 3×16 rm | 17,70 | 733 | 1,15 | 80 | 98 |
4 DAMARLI / 4 CORES
| 4×1,5 re | 9,30 | 144 | 12,10 | 18,5 | 22 |
| 4×2,5 re | 10,20 | 191 | 7,41 | 25 | 30 |
| 4×4 re | 12,20 | 290 | 4,61 | 34 | 40 |
| 4×6 re | 13,80 | 395 | 3,08 | 43 | 51 |
| 4×10 rm | 17,35 | 625 | 1,83 | 60 | 70 |
| 4×16 rm | 20,00 | 913 | 1,15 | 80 | 98 |
5 DAMARLI / 5 CORES
| 5×1,5 re | 10,00 | 169 | 12,10 | 18,5 | 22 |
| 5×2,5 re | 11,00 | 226 | 7,41 | 25 | 30 |
| 5×4 re | 13,55 | 358 | 4,61 | 34 | 40 |
| 5×6 re | 14,90 | 474 | 3,08 | 43 | 51 |
| 5×10 rm | 17,80 | 756 | 1,83 | 60 | 70 |
| 5×16 rm | 22,20 | 1131 | 1,15 | 80 | 98 |
